COPPER (Cu)
Copper, silver and gold are in group 11 of the periodic table, and they share the attributes of high ductility and electrical and themal conductivity. Another attribute that this three metals share is that they are found as a pure metal in nature, making it the first source of metals to be used by humans. Copper is soft, easy to alloy, corrosion resistant, antibacterial, non-magnetic, recyclable, and a catalyst.
That is why it´s applications covers sectors such as electric power, automotive, construction, telecommuncations, machinery, aviation, as well as precision instruments and watches. The red metal´s ductility and low electric resistance has made it the ideal element for conductivity according to the International Annealed Copper Standard (IACS).
PROPERTIES
It´s main function its to elaborate Copper Wire Rod, that its transformed later to electric wires.
APPLICATIONS
PROPERTIES
It is used in the manufacture of metallic electrical conductors. It is applied on a large scale in the production of wire cables for transmission of electric and thermal energy, electric-electronics, busbars, electrical contacts, telephony, telecommunications, power transmission, automotive, construction and also in the computer industry.
-
99.99% continuously cast electrolytic copper rod
-
Total impurity without oxygen ≤ 45ppm (Typical ≤ 28ppm)
-
Electrical Conductivity 101% IACS (min.)
-
Tensile Strength 4.5 Kg/mm2
-
Elongation Test 35% (min.)
-
ASTM B 49-98, ASTM B 115-00, BS EN 1976-1978, BS EN 1978-1998
APPLICATIONS
PROPERTIES
Its main use is in the manufacture of electrical conductors. It is also frequently used in the production of electronic devices, motors, generators, transformers, with a presence in the automotive industry, civil construction and in the telephone and computer sectors.
-
Diameter: 1.450 mm, 1.828 mm, 2.588 mm, 2.053 mm, other gauges required by customers.
-
Total impurity excluding oxygen (Typical ≤ 25ppm)
-
Continuous annealing, except when the customer requires hard-drawn copper wire.
-
Electrical Conductivity ≥ 100% IACS
-
Elongation for Annealed Copper Wire ≥ 25%
-
Elongation for Hard-Drawn Copper Wire 1.2
-
ASTM B3-90, NBR 5111-97, NBR 5471-86, NBR 14733-01, ASTM B01-01
